It-12-il 13th Motherboards Industrijali Inkorporati H-ADLP02
Ibbażat fuq il-pjattaforma tal-qalba Intel 12/13 Generation
2 SO-DIMM DDR4 Slot tal-memorja ta 'espansjoni, appoġġ sa 64GB
1 M.2 Key-E 2230 Interface, Expand Wi-Fi + BT Modulu
1 M.2 Interface Key-M, Expand NVME / SATA Modulu ta 'Ħażna Adattiva
Appoġġ HDMI / EDP Display Output
1 10 / 100 / 1000m Ethernet
Espansjoni massima ta '10 USB, 4 com
DC 12 / 24V Provvista ta 'Enerġija
Ibgħat l-inkjesta
Product Details ofIt-12-il 13th Motherboards Industrijali Inkorporati H-ADLP02
Il-motherboards industrijali inkorporati H-ADLP02 għandhom is-serje Intel 12/13-il ġenerazzjoni Core-U / P. Huwa jappoġġja sa 32GB ta 'DDR 4 3200 MT / S MEMORJA SO-DIMM u jinkludi għażliet ta' konnettività multipli bħal HDMI + EDP + EDP għal wirja tripla, 4 x USB3.0 jew 3X USB 3.0+1 x TYPE-C, 1 HSIO, 4 RS 232 COM PORTS, 1 RJ45 LAN, u 2 Slots. Huwa jappoġġja wkoll Wake On LAN, l-ebda gwida tad-diska, u l-poter awtomatiku. Din il-motherboard hija adattata għal diversi applikazzjonijiet inklużi kjosks bl-imnut, self-service, magni kollha-in-one, u sistemi ta 'kontroll industrijali.
H-ADLP02
| Proċessur | Intel® 12th / 13th Alder Lake / Raptor Lake Processor (jappoġġja s-serje U / P) |
| Chipset | Intel Soc |
| Uri kontrollur | Intel CPU Integrat UHD Display Controller |
| Port tal-wiri | HD + EDP + EDP Appoġġ Triple Display Riżoluzzjoni HDI Max 4096x2160 @ 30Hz EDP Max Resolution 1920 * 1080 @ 60Hz |
| Memorja | 1 * DDR4 Slot RAM, Max 32 GB |
| Ħażna | 1xsata3.0, 1xm .2 2242 / 2280 interface jappoġġja SSD ma 'SATA / NVME |
| Awdjo | L-IO ta 'wara jappoġġja mic-in / line-out b'żewġ f'wieħed, jappoġġja 2W / 8ω, 3W / 4Ω power u output tal-amplifikatur |
| LAN | 1XRJ45 Gigabit Ethernet Port RTL8111h |
| USB | IO ta 'wara: 4 X USB3.0 (double-saff USB 3.0 TIP-A) jew 3X USB 3.0+1 X TYPE-C Abbord: 1x 2 * 5pin wejfer, 2x 1 * 1pin wejfer, edp1, interface edp2 built-in 3 interfaces USB2.0, total ta '11 -il usb jista 'jiġi estiż |
| Port parallel | 1 lpt 2 * 13pin Header Parallel Port |
| Com |
4 portijiet tas-serje RS232 |
| Xarabank ta 'espansjoni | 1 M.2 Key-M (Adaptive SATA / PCIE X2) 1 m.2 key-e (pcie x 1+ sinjal USB2.0) |
| Portijiet oħra | 1x f_panel, 1x sata_conn (fpc), 1x cpu_fan, 1x prt_cash |
| Temperatura u umdità | Temperatura tal-Ħażna u Umdità: -20 ~ 75 Grad 10% ~ 90%, Non-Condensing Temperatura u Umdità tax-Xogħol: 0 ~ 60 grad 10% ~ 90%, li ma jikkondensax |
| Sistema operattiva | Windows 10/11, Linux |
| BIOS | Ami uefi bios |
| Funzjoni oħra | Watch Dog, No Disk Startup, Network Wake Up, Power On, Startup Timed |
| Provvista ta 'enerġija | DC-in 12V |
| Daqs tal-PCB | 151mm * 120mm (l * w) |
| Mudell | CPU | LVDs | EDP | HD | VGA | LAN | USB | Com | M.2 | Tip-C | |
| 3.0 | 2.0 | ||||||||||
| HN-1215D14-2E | 1215U |
/
|
2
|
1 | / | 1 | 4 | 7 | 4 | 2 | / |
| HN-1235D14-2E | 1235u |
/
|
2
|
1 | / | 1 | 4 | 7 | 4 | 2 | / |
| HN-1315D14-2E | 1315u |
/
|
2
|
1 | / | 1 | 4 | 7 | 4 | 2 | / |
| HN-1215D14-T2E | 1215U | / |
2
|
1 | / | 1 | 3 | 7 | 4 | 2 | 1 |
| HN-1235D14-T2E | 1235u |
/
|
2
|
1 | / | 1 | 3 | 7 | 4 | 2 | 1 |
| HN-1315D14-T2E | 1315u | / |
2
|
1 | / | 1 | 3 | 7 | 4 | 2 | 1 |
